DELLENT Isuzu Diesel Generator 110kVA 60Hz 3 Phase With Smartgen Controller

  • DELLENT Isuzu Diesel Generator 110kVA 60Hz 3 Phase With Smartgen Controller
Place of Origin CHINA
Brand Name DELLENT-ISUZU
Certification CE ISO
Model Number DE-IS110
Document Product Brochure PDF
Minimum Order Quantity 1*20GP
Price face to face
Packaging Details PLASTIC WRAP
Delivery Time 20-30 DAYS
Payment Terms L/C, T/T
Supply Ability 500 PCS PER MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Isuzu Diesel Generator Brand ISUZU
Cooling System Water Cooling Frequency 60HZ
Alternator Tamford/ Leroy Somer/ Mecc Alte Controller Model Deepsea/ ComAp/Smartgen
Phase Three Phase Type Diesel Generator
Controller Smartgen DSE Engine Model 6BG1-Z1
Prime Power 100kVA/80kW Standby Power 110kVA/88kW
Highlight

Isuzu Diesel Generator 110kVA

,

Isuzu Diesel Generator 3 Phase
Leave a Message
Product Description

Isuzu Diesel Generator Set 110kVA 60Hz 3 Phase With Smartgen Controller





 Light:

Commercial ISUZU100kVA Generator

,6BG1-Z1

 Engine Diesel  Generator

,

CE ISUZU 100kVA Generator ,60HZ

Ⅰ.PRODUCT DESCRIPTION

100kVA 80kW 60Hz Isuzu Diesel Generator With 6BG1-Z1 Engine
Product Introduce:
Our Isuzu engine diesel generator have all series from 20kva to 106kva.Isuzu diesel engine which features reliable starting performance, environmental protection, low vibration, and energy-saving, etc. Benefiting from the engine's characteristics, the Isuzu diesel generator set features stable and reliable work at running.
Application fields:
Diesel generator are used in any situation where a reliable backup power source is necessary to maintain continuity of operations.
Advantage of our Isuzu diesel generator :
Isuzu diesel generator have a sturdy housing；
Longer lifespan；
Lower maintenance costs；
Lower noise level；
Faster delivery time；
Better team service；
Higher level technical support.
Product parameters:
Generator Set Specification
Model DE-IS110
Max. Power kVA 110
kW 88
Rate Power kVA 100
kW 80
Frequency Hz 60
Rate Voltage V 220/127
Rate Current A 262.4
Dimension For Open-type Genset mm 2250 X 930 X 1500
Weight For Open-type Genset kg 890
Dimension For Soundproof Genset mm 2900 X 1050 X 1300
Weight For Soundproof Generator kg 1400



Technical Data of ISUZU Diesel Engine:

Engine Manufacturer Isuzu Engine Co., Ltd.
Engine Brand Isuzu
Engine Model 6BG1-Z1
No. of Cylinder 6 Cylinder in line
Aspiration   Turbocharged
Governor Mechanical
Engine Max. Output Power kW 105
Displacement L 5.9
Starting Voltage V 24
Bore mm 102
Stroke mm 118
Lubrication Oil Capacity L N.A.
Control Panel Specification:
Controller Brand Smartgen
Breaker Brand Delixi
Breaker Capacity (A) 80
Battery Charger Smartgen
Emergency Stop Button Supply
Automatic Mains Fail (AMF) Supply
Fuel Level Supply
Automatic Transfer Switch ATS as optional part
The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).
Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

Ⅱ. Why Choose Us:

DELLENT Isuzu Diesel Generator 110kVA 60Hz 3 Phase With Smartgen Controller 0

Ⅲ. QUALIFICATION CENTIFICATE:DELLENT Isuzu Diesel Generator 110kVA 60Hz 3 Phase With Smartgen Controller 1

Ⅳ. FACTORY INTERIOR:

DELLENT Isuzu Diesel Generator 110kVA 60Hz 3 Phase With Smartgen Controller 2



FAQ



Q: What's your delivery time?

A: Standard product 20 days - 30 days. 0



Q: Can we add our logo to products?

A: Yes, there are several ways to do this. We can put the label of your logo on the products or make the silk print of your logo on the products. It is free.



Q: Can we customize the product?

A: We have a very experienced technical team, we can customize any product according to your requirements, such as synchronization system, wet exhaust system, ultra-silent system



If you need ISUZU generator with other models technical data, kindly contact us for catalogues!
