6HTAA6.5-G22 SDEC Diesel Generator 150kVA Open Type Genset

  • 6HTAA6.5-G22 SDEC Diesel Generator 150kVA Open Type Genset
Place of Origin CHINA
Brand Name DELLENT
Certification CE/ISO9001
Model Number DE-SC165
Document Product Brochure PDF
Minimum Order Quantity 1*20GP
Price face to face
Packaging Details PLASTIC WRAP OR PLYWOOD CASE
Delivery Time 30 DAYS FROM DEPOSIT RECEIVED
Payment Terms L/C, T/T
Supply Ability 500 PCS PER MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name SDEC Diesel Generator Open Type Engine Model 6HTAA6.5-G22
Frequency 50Hz Engine Brand SDEC
No. Of Cylinder 6 Cylinder In Line Rated Speed 1500rpm
Voltage 400V/230V Warranty 12 Months
Controller Deepsea/Smartgen/ ComAp Prime Power 120kW/150kVA
Standby Power 132kW/165kVA
Highlight

SDEC Diesel Generator 150kVA

,

SDEC Diesel Generator Open Type

,

150kVA Open Type Genset
Leave a Message
Product Description

6HTAA6.5-G22 SDEC Diesel Engine 150kVA Open Type Genset

Ⅰ. PRODUCT DESCRIPTION

150kVA Standby Power SDEC Genset Soundproof Engine By 6 Cylinder In Line.Dellent Power supply the standby power 150kVA water cooled diesel generator with SDEC brand diesel engine model6HTAA6.5-G22. The water cooled diesel generator with rated output 165kVA /132kW, standby power150kVA /120kW.



1. Diesel generators are strong-built, ideal for emergency back-up,job sites and industrial appplications.

2. Powered by reliable air/water cooled diesel generators sets, industrial grade, great fuel efficiency, less maintenance, long operating life.

3. Strong technology and high-quality personnel, continuous innovation and perfect management.

6HTAA6.5-G22 SDEC Diesel Generator 150kVA Open Type Genset 0

150kVA Diesel Generator Powered by SDEC Diesel Engine:

Model DE-SC165
Max. Power kVA 165.0
kW 132.0
Rate Power kVA 150.0
kW 120.0
Frequency Hz 50
Rate Voltage V 400/230
Rate Current A 216.5



Specification of the Diesel Engine:

Engine Manufacturer Shanghai Diesel Engine Co., Ltd.
Engine Brand SDEC
Engine Model 6HTAA6.5-G22
No. of Cylinder 6 Cylinder in line
Aspiration Turbocharged and Air to Air Aftercooled
Governor Electric
Engine Max. Output Power kW 155
Displacement L 6.500
Starting Voltage V 24
Bore mm 105
Stroke mm 124
Lubrication Oil Capacity L 15-17.5
Compression Ratio 16 : 1
Intake Air Flow M3/Min N.A
Fuel Consumption at 100% Load L 33.1




Specification of Automatic Control Panel:



Controller Brand Deepsea
Controller Model DSE6120
Breaker Brand Delixi
Breaker Capacity A 250
Battery Charger Smartgen Model BAC06A
Emergency Stop Button Supply
Automatic Mains Fail (AMF) Supply
Fuel Level Supply
Automatic Transfer Switch ATS as optional part
Mains Monitor Supply with DELLENT Function
The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).
Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

Ⅱ. Why Choose Us:

6HTAA6.5-G22 SDEC Diesel Generator 150kVA Open Type Genset 1Ⅲ. QUALIFICATION CENTIFICATE:

6HTAA6.5-G22 SDEC Diesel Generator 150kVA Open Type Genset 2

Ⅳ. FACTORY INTERIOR:

6HTAA6.5-G22 SDEC Diesel Generator 150kVA Open Type Genset 3
