88kVA Standby Power Perkins Diesel Generator Set 1104A-44TG2

  • 88kVA Standby Power Perkins Diesel Generator Set 1104A-44TG2
Place of Origin CHINA
Brand Name DELLENT-PERKINS
Certification CE ISO
Model Number DE-P88
Document Product Brochure PDF
Minimum Order Quantity 1PC
Price face to face
Packaging Details PLASTIC WRAP
Delivery Time 30 DAYS
Payment Terms L/C, T/T
Supply Ability 500 PCS PER MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name 88kVA Diesel Generator Brand Perkins
Cooling System Water Cooling Frequency 50/60HZ
Alternator Alternator Phase Three Phase
Type Diesel Generator Controller Smartgen DSE
Engine Model 1104A-44TG2
Highlight

ISO Perkins Diesel Generator Set

,

88kVA Diesel Generator

,

Perkins 1104A-44TG2
Leave a Message
Product Description

1104A-44TG2 50Hz 88kVA Standby Power Perkins Diesel Generator Set





High Light:

Commercial Perkins 88kVA Generator

,

1104A-44TG2 Engine Diesel  Generator

,

CE Perkins 88kva Generator ,50/60HZ

Ⅰ.PRODUCT DESCRIPTION

1104A-44TG2 50Hz 88kVA Standby Power Perkins Diesel Generator Set
Product Introduce:Dellent Power Perkins Series generator powered by the original Perkins engine, it enjoys high stability, reliability, durability, and long life with a wide range of power output. It is widely used in the area of the port, railway, industrial, and mining.
88kVA Standby Power Perkins Diesel Generator Set 1104A-44TG2 088kVA Standby Power Perkins Diesel Generator Set 1104A-44TG2 1

Product parameters:

Specification of Soundproof Diesel Generator:

Model DE-P88
Max. Power kVA 88
kW 70.4
Rate Power kVA 80
kW 64
Frequency Hz 50
Rate Voltage V 400/230
Rate Current A 115.5
Fuel Tank Capacity L 160
Dimension For Open-type Genset mm 1860 X 750 X 1200
Weight For Open-type Genset kg 1052
Dimension For Soundproof Genset mm 2500 X 1080 X 1500
Weight For Soundproof Generator kg 1500
Noise Level for Soundproof Generator dBA 70dBA at 7 Meters
Battery One of 80A Free Maintenance Battery


Specification of Perkins Diesel Engine:

Engine Manufacturer Perkins
Engine Brand Perkins
Engine Model 1104A-44TG2
No. of Cylinder 4 Cylinder in line
Aspiration Turbocharged and Air to Air Aftercooled
Governor Mechanical
Engine Max. Output Power kW 82.5
Displacement L 4.4
Compression Ratio 17.25 : 1
Starting Voltage V 12
Bore mm 105
Stroke mm 127
Lubrication Oil Capacity L 7
Intake Air Flow M3/Min 5.28
Fuel Consumption at 100% Load L/H 18.7

Specification of Control Panel for Soundproof Diesel Generator:

Controller Brand Deepsea
Controller Model DSE
Breaker Brand Delixi6120
Breaker Capacity (A) 125
Emergency Stop Button Supply
Automatic Mains Fail (AMF) Supply
Fuel Level Supply
Automatic Transfer Switch ATS as optional part
The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).
Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.



Ⅱ. Why Choose Us:

88kVA Standby Power Perkins Diesel Generator Set 1104A-44TG2 2

Ⅲ. QUALIFICATION CENTIFICATE:88kVA Standby Power Perkins Diesel Generator Set 1104A-44TG2 3

Ⅳ. FACTORY INTERIOR:

88kVA Standby Power Perkins Diesel Generator Set 1104A-44TG2 4



Advantages:



Compact Design: Our generator with Perkins engine is designed to be compact and easy to transport, making it ideal for use in a variety of locations. Its small size also makes it easy to store when not in use, freeing up valuable space in your workshop or storage area.



Quiet Operation: With its advanced noise reduction technology, our generator with Perkins engine operates at low noise levels, making it ideal for use in noise-sensitive environments. This makes it a great choice for residential and commercial use, where noise pollution is a concern.



If you need Perkins generator with other models technical data, kindly contact us for catalogues!
