410kW 60Hz Cummins Generator Set Open Type With KTA19-G3 Engine

  • 410kW 60Hz Cummins Generator Set Open Type With KTA19-G3 Engine
Place of Origin CHINA
Brand Name DELLENT
Certification CE/ISO9001
Model Number DE-CC563
Document Product Brochure PDF
Minimum Order Quantity 1 PC
Price bargain face-to-face
Packaging Details PLASTIC WRAP OR PLYWOOD CASE
Delivery Time 20-30 DAYS
Payment Terms L/C, T/T
Supply Ability 1 MONTH 600PCS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Engine Brand Cummins Engine Model KTA19-G3
Name 60Hz Cummins Generator Set Cooling Method Water-Cooling System
Fuel Type Diesel Prime Power 512.5kVA/410kW
Standby Power 562.5kVA /450kW Rated Frequency 60HZ
Speed 1800RPM8 Warranty 12 Months/1000 Hours
Genset Type Open Type
Highlight

410kW Cummins Generator Set

,

60Hz Cummins Generator Set

,

Cummins Generator Set Open Type
Leave a Message
Product Description

410kW 60Hz Cummins Generator Set Cummins Power Generator With KTA19-G3 Engine

Ⅰ. PRODUCT

410kW 60Hz Cummins Generator Set Open Type With KTA19-G3 Engine 0

 Cummins Engine Generator:

Model A-C563H
Standby Power kVA 563
kW 450
Prime Power kVA 513
kW 410
Frequency Hz 60
Output Voltage V 240
Oil Consumption L/H 0.352157015
Dimension For Open-type mm 3475 X 1250 X 1920
Weight For Open-type kg 3650

Cummins Diesel Engine:

Engine Model KTA19-G3
No.of Cylinder 6 Cylinder in line
Bore mm 159
Stroke mm 159
Displacement L 18.9
Cooling Fan Air Flow m3/min 588
Compress Air Flow m3/min 34.7
Exhaust Gas Flow m3/min 96.2
Exhaust Gas Temperature ℃ 557
Lubrication Oil Capacity L 50
Cooling Water Capacity L 91
Starting Voltage V 24
Engine Max.Output Power kW 511

The Control Panel :

Alternator Brand Stamford
Rate Output kVA 594
Frequency Hz 60
Altitude M ≤1000
Insulation Class H
Protection Grade IP23
Alternator for choice We also have Leroy Somer, Marathon, Mecc Alte and Chinese brand Brushless alternator for your choice.








Ⅱ. Why Choose Us:

410kW 60Hz Cummins Generator Set Open Type With KTA19-G3 Engine 1

Ⅲ. QUALIFICATION CENTIFICATE:

410kW 60Hz Cummins Generator Set Open Type With KTA19-G3 Engine 2

Ⅳ. FACTORY INTERIOR:

410kW 60Hz Cummins Generator Set Open Type With KTA19-G3 Engine 3

Competitive Advantage:

1. Low fuel consumption

2. Good quality engine and alternator

3. Fast delivery. 20-30 days

4. The generator set is mounted on a heavy-duty fabricated steel skid type base– frame with anti-vibration mounting pads.

5. Side doors are mounted on both sides, convenient for daily checks and maintenance.

6. External oil filter design can ensure fuel safety when generating sets outside.

7. Use high standard of sponge to make it soundproof.
