50Hz 200kva Genset Standby Power 1106A-70TAG3 Perkins Diesel Generator Set

  • 50Hz 200kva Genset Standby Power 1106A-70TAG3 Perkins Diesel Generator Set
Place of Origin CHINA
Brand Name DELLENT-PERKINS
Certification CE ISO
Model Number DE-P200
Document Product Brochure PDF
Minimum Order Quantity 1PC
Price face to face
Packaging Details PLASTIC WRAP
Delivery Time 30 DAYS
Payment Terms L/C, T/T
Supply Ability 500 PCS PER MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name 200 Kva Power Generator Cooling System Water Cooling
Frequency 50HZ Alternator Alternator
Phase Three Phase Brand Perkins
Type Diesel Generator Controller Smartgen DSE
Engine Model 1106A-70TAG3 Prime Power 144kVA/180kW
Standby Power 160kVA/200kW
Highlight

200kva Genset

,

200 Kva Power Generator

,

1106A-70TAG3 Perkins Diesel Generator Set
Leave a Message
Product Description

50Hz 200kVA Standby Power With 1106A-70TAG3 Of Perkins Diesel Generator Set





High Light:

Commercial Perkins 200kVA Generator

,

1106A-70TAG3 Engine Diesel  Generator

,

CE Perkins 200kva Generator ,50HZ

Ⅰ.PRODUCT DESCRIPTION

50Hz 200kVA Standby Power with 1106A-70TAG3 of Perkins Diesel Generator Set
Product Introduce:Dellent Power Perkins Series generator powered by the original Perkins engine, it enjoys high stability, reliability, durability, and long life with a wide range of power output. It is widely used in the area of the port, railway, industrial, and mining.
50Hz 200kva Genset Standby Power 1106A-70TAG3 Perkins Diesel Generator Set 0

Product parameters:

Specification:

Model DE-P200
Max. Power kVA 200
kW 160
Rate Power kVA 182
kW 145
Frequency Hz 50
Rate Voltage V 400/230
Rate Current A 261.6


Specification of Perkins Diesel Engine:

Engine Manufacturer Perkins Engines Company Limited
Engine Brand Perkins
Engine Model 1106A-70TAG3
No. of Cylinder 6 Cylinder in line
Aspiration Turbocharged and Air to Air Aftercooled
Governor Electric
Engine Max. Output Power kW 179.8
Displacement L 7.0
Compression Ratio 16.0 : 1
Starting Voltage V 12
Bore mm 105
Stroke mm 135
Lubrication Oil Capacity L 16.5
Intake Air Flow L/S N.A.
Fuel Consumption at 100% Load L/H 38.2

Specification of Control Panel :

Control Panel Specification
Controller Model Leroy Somer alternator
Breaker Brand DSE6120
Breaker Capacity (A) 262
Emergency Stop Button Supply
Automatic Mains Fail (AMF) Supply
Fuel Level Supply
Automatic Transfer Switch ATS as optional part
The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).
Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

Ⅱ. Why Choose Us:

50Hz 200kva Genset Standby Power 1106A-70TAG3 Perkins Diesel Generator Set 1

Ⅲ. QUALIFICATION CENTIFICATE:50Hz 200kva Genset Standby Power 1106A-70TAG3 Perkins Diesel Generator Set 2

Ⅳ. FACTORY INTERIOR:

50Hz 200kva Genset Standby Power 1106A-70TAG3 Perkins Diesel Generator Set 3



If you need Deutz generator with other models technical data, kindly contact us for catalogues!
