DELLENT 200KW Diesel Generator 275kVA 50Hz Standby Generator Set Doosan P126TI

  • DELLENT 200KW Diesel Generator 275kVA 50Hz Standby Generator Set Doosan P126TI
Place of Origin CHINA
Brand Name DELLENT-Doosan
Certification CE ISO
Model Number DE-DS275
Document Product Brochure PDF
Minimum Order Quantity 1PC
Price face to face
Packaging Details PLASTIC WRAP
Delivery Time 30 DAYS
Payment Terms L/C, T/T
Supply Ability 500 PCS PER MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Brand Doosan Cooling System Water Cooling
Frequency 50HZ Alternator Stamford
Phase Three Phase Type Diesel Generator
Controller Smartgen Engine Model P126TI
Rate Current 360.9A Name 200kw Diesel Generator
Highlight

50Hz Standby Generator Set

,

200KW Diesel Generator 275kVA

,

Doosan P126TI
Leave a Message
Product Description
High Light:

Commercial Doosan 275kVA Generator

,P126TI

 Engine Diesel  Generator

,

CE Doosan 275kva Generator ,50HZ

Ⅰ.PRODUCT DESCRIPTION

50Hz 275kVA Standby Power with P126TI of Doosan Diesel Generator Set
Product Introduce:Dellent Power Doosan Series generator powered by the original Doosan engine, it enjoys high stability, reliability, durability, and long life with a wide range of power output. It is widely used in the area of the port, railway, industrial, and mining.
DELLENT 200KW Diesel Generator 275kVA 50Hz Standby Generator Set Doosan P126TI 0

Product parameters:

Specification of 150kVA Emergency Standby Generator:

Model DE-DS275
Max. Power kVA 275
kW 220
Rate Power kVA 250
kW 200
Frequency Hz 50
Rate Voltage V 400/230
Rate Current A 360.9
Fuel Tank Capacity L 450
Dimension For Open-type Genset mm 2850 X 1020 X 1660
Weight For Open-type Genset kg 2490
Dimension For Soundproof Genset mm 3700X 1300 X 1700
Weight For Soundproof Generator kg 3350
Noise Level for Soundproof Generator at 7M dBA 78


Specification of Doosan Diesel Engine P126TI:

Engine Manufacturer Doosan Infracore
Engine Brand Doosan
Engine Model P126TI
No. of Cylinder 6 Cylinder in line
Aspiration Turbocarged
Governor Electric
Engine Max. Output Power kW 272
Displacement L 11.1
Compression Ratio 17 : 1
Starting Voltage V 24
Bore mm 123
Stroke mm 155
Lubrication Oil Capacity L 23
Intake Air Flow M3/Min 16.4
Fuel Consumption at 100% Load L/H 61.1

Specification of Control Panel :

Specification of Control Panel for 275kVA Emergency Standby Generator:

Controller Brand Smartgen
Controller Model HGM6120N
Breaker Brand Delixi
Breaker Capacity (A) 630
Emergency Stop Button Supply
Automatic Mains Fail (AMF) Supply
Fuel Level Supply
Automatic Transfer Switch ATS as optional part
The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).
Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

Ⅱ. Why Choose Us:

DELLENT 200KW Diesel Generator 275kVA 50Hz Standby Generator Set Doosan P126TI 1

Ⅲ. QUALIFICATION CENTIFICATE:DELLENT 200KW Diesel Generator 275kVA 50Hz Standby Generator Set Doosan P126TI 2

Ⅳ. FACTORY INTERIOR:

DELLENT 200KW Diesel Generator 275kVA 50Hz Standby Generator Set Doosan P126TI 3



If you need Deutz generator with other models technical data, kindly contact us for catalogues!
