DELLENT 50KW Diesel Generator Silent Three Phase SDEC Genset

  • DELLENT 50KW Diesel Generator Silent Three Phase SDEC Genset
Place of Origin CHINA
Brand Name DELLENT-SDEC
Certification CE/ISO9001
Model Number DE-SC63
Document Product Brochure PDF
Minimum Order Quantity 1*20GP
Price face to face
Packaging Details PLASTIC WRAP OR PLYWOOD CASE
Delivery Time 30 DAYS FROM DEPOSIT RECEIVED
Payment Terms L/C, T/T
Supply Ability 500 PCS PER MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Engine Model 4HT4.3-G21 Frequency 50Hz
Engine Brand SDEC No. Of Cylinder 4 Cylinder In Line
Rated Speed 1500rpm Voltage 400V/230V
Warranty 12 Months Controller Automatic Start/Stop
Prime Power 45kW/56kVA Standby Power 50kW/63kVA
Alternator Type Brushless Name 50KW Diesel Generator
Highlight

SDEC 50KW Diesel Generator

,

50KW Diesel Generator Silent

,

Three Phase SDEC Genset
Leave a Message
Product Description

Three Phase SDEC Engine 50Hz 50kW Silent Diesel Generator

Ⅰ. PRODUCT DESCRIPTION

50kVA Standby Power SDEC Genset Soundproof Engine By 4 Cylinder In Line.Dellent Power supply the standby power 50kVA water cooled diesel generator with SDEC brand diesel engine model4HT4.3-G21. The water cooled diesel generator with rated output 56kVA /45kW, standby power63kVA /50kW.

DELLENT 50KW Diesel Generator Silent Three Phase SDEC Genset 0DELLENT 50KW Diesel Generator Silent Three Phase SDEC Genset 1

50kVA Diesel Generator Powered by Ricardo Diesel Engine:

Model DE-SC63
Max. Power kVA 63
kW 50
Rate Power kVA 56
kW 45
Frequency Hz 50
Rate Voltage V 400/230
Rate Current A 80.83

Specification of the Diesel Engine:

Engine Manufacturer Shanghai Diesel Engine Co., Ltd.
Engine Brand SDEC
Engine Model 4HT4.3-G21
No. of Cylinder 4 Cylinder in line
Aspiration Turbocharged
Governor Electric
Engine Max. Output Power kW 56
Displacement L 4.300
Starting Voltage V 24
Bore mm 105
Stroke mm 124
Lubrication Oil Capacity L 11-13
Compression Ratio 17.3 : 1
Intake Air Flow M3/Min N.A
Fuel Consumption at 100% Load L 12.8

Specification of Automatic Control Panel:

Controller Brand ComAp
Breaker Brand Delixi
Breaker Capacity A 63
Battery Charger Smartgen Model BAC06A
Emergency Stop Button Supply
Automatic Mains Fail (AMF) Supply
Fuel Level Supply
Automatic Transfer Switch ATS as optional part
Mains Monitor Supply with DELLENT Function
The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).
Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

Ⅱ. Why Choose Us:

DELLENT 50KW Diesel Generator Silent Three Phase SDEC Genset 2Ⅲ. QUALIFICATION CENTIFICATE:

DELLENT 50KW Diesel Generator Silent Three Phase SDEC Genset 3

Ⅳ. FACTORY INTERIOR:

DELLENT 50KW Diesel Generator Silent Three Phase SDEC Genset 4
